4 IP channels up to 4K/8MP
-
Video compression: Smart H.265+, H.265, Smart H.264+, H.264
-
Simultaneous HDMI (4K) and VGA (1080P) video outputs
-
Output division: 1, 4
-
1 RCA input / 1 RCA audio output
-
Two-way audio via RCA input/output
-
Audio compression: G.711a, G.711u, PCM, G726
-
Recording Resolution: 4K/8MP, 5MP, 4MP, 3MP, 1080P, 720P, D1, CIF
-
Bandwidth: 80 Mbps for access, 80 Mbps for storage and 60 Mbps for transfer
-
Decode capability: 2 channels at 8MP (25 fps), 4 channels at 4MP (25 fps), 4 channels at 1080P (25 fps)
-
Manual, alarm, motion detection and scheduled recording modes
-
Video sensor, privacy mask, video loss, IP camera alarm
-
Playback of up to 4 channels
-
Internal capacity for 1 SATA hard drive up to 10TB (sold separately)
-
New user interface with a simpler user experience
-
Supports perimeter protection, SMD Plus, and heatmap features of compatible Dahua cameras
-
Supports intelligent metadata search
-
Supports ANR (Automatic Network Replenishment Technology): in the event of a network failure, images are saved to the IP camera's SD card, which are transferred to the NVR once the network is restored
-
Watchdog software and hardware
-
Watermark to preserve video integrity
-
RJ45 Fast Ethernet network port (10/100Mbps)
-
Network Protocols: HTTP, HTTPS, TCP/IP, IPv4, RTSP, UDP, NTP, DHCP, DNS, P2P
-
ONVIF (Profile S), CGI and SDK compliant
-
Remote access from web browser (IE9, Chrome, Firefox) and iPhone, iPad (iDMSS) and Android (gDMSS) devices
-
Server Access to the local network and Internet
-
Ability to limit user access to cameras in local and/or remote mode
-
Can be controlled remotely by Joystick keyboard connected by TCP/IP
-
Sending emails with photo attachment in case of alarm
-
Send to programmed FTP or alarm
-
Ability to send an alarm and be connected to the software of the video surveillance receiver
-
Possibility of fixed or dynamic IP via Dyndns service, NoIP, DDNS Evolution, etc.
-
Communication ports: 2 USB 2.0 ports
-
Power supply: 12V DC/2A (≤10W, not counting drives)
-
-10°C~+55°C operating temperature
-
10%~90% relative humidity
-
Dimensions: 260 (W) x 50.3 (H) x 232.5 mm
-
Weight: 810 g
-
Desktop installation
